2.1 Fiber1 Video
Out This parameter selects which video processor output is sent to the optional Fiber1
output. The default is to send the output of Processor 1 to Fiber1 Out. The
Proc1+Proc2 selection multiplexes two separate 1.5 Gb HD video signals from both
video processor outputs into a Dual Stream 3G SDI (muxed) output. This selection
produces valid video only if both video processors are set to the same HD video
output format (but not 1080p50/60). See 1.1 SDI1 Video Output for an illustration.
2.2 Fiber2 Video
Out This parameter selects which video processor output is sent to the optional Fiber2
output. The default is to send the output of Processor 2 to the Fiber2 Output. The
Proc1+Proc2 selection multiplexes two separate 1.5 Gb HD video signals from both
video processor outputs into a Dual Stream 3G SDI (muxed) output. This selection
will only produce valid video if both video processors are set to output the same HD
video format and that format is not 1080p50/60. See 1.1 SDI1 Video Output for an
illustration.
3 HDMI Video
Out This parameter selects which video processor output is sent to the HDMI output.
4 Component
Out This parameter selects the video processor output to be sent out the Component
analog output.
2.1 Fiber1 Video Out Selections Selection Descriptions
Processor1 (default)
Processor2
Proc1+Proc2
Sends the output of Processor 1 to the Fiber1 output.
Sends the output of Processor 2 to the Fiber1 output.
Sends multiplexed Proc 1 & 2 to the Fiber1 output (Dual Stream 3G).
2.2 Fiber2 Video Out Selections Selection Descriptions
Processor1
Processor2 (default)
Proc1+Proc2
Sends the output of Processor 1 to the Fiber2 output.
Sends the output of Processor 2 to the Fiber2 output.
Sends multiplexed Proc 1 & 2 to the Fiber2 output (Dual Stream 3G).
3 HDMI Video Out Selections Selection Descriptions
Processor1 (default)
Processor2
Sends the output of Processor 1 to the HDMI output.
Sends the output of Processor 2 to the HDMI output.
4 Component Out Selections Selection Descriptions
Processor1 (default)
Processor2
Sends the output of Processor 1 to the Component output.
Sends the output of Processor 2 to the Component output.
