2 Output Format This parameter defines the output format of the Video Processor (1 or 2). Available
choices depend on the frame rate selection. The frame rate is set by the Frame Rates
parameter (System menu 9).
Notes:
1. Output Format Selection Constraint—Available frame rates depend on System 9
Frame Rates parameter setting.
2. Output Follow Ref Exception—If the parameter 2 Output Format is set to Follow
Ref, and the 8 Genlock Source is set to Input, and the 1 Video Input is set to select one
of the analog inputs, the output format will follow the input format rather than the
format of the signal on the Ref BNC as might be expected. (This combination of
settings effectively disconnects the Ref BNC.)
3. Output Timing Memory—Changing the Output Format selection automatically
selects new values for H & V timing parameters (14.1 Output Timing H, 14.2 Output
Timing V and 14.3 Analog Output Fine). Each Output Format mode remembers its
own H and V timing settings.
4. Output Format Mapping—The Output Format selection is remembered for each
of the frame rates. If you change the frame rate selection, the Output Format
associated with the newly selected frame rate is recalled.
3 Video Output
Mode The parameter sets the final video output of the Video Processor to normal video or
the test pattern generator. Alarms occur if conflicting video formats are selected.
2 Output Format Selections Selection Descriptions
Follow INPUT (default)
Follow REF
525/625
720p
1080i
1080PsF
1080p
2K1080p
Follow the format of the selected input.
Follow the format of the reference input (Ref ).
Select 525/625 SD as the Video Processor output.
Select 720p HD as the Video Processor output.
Select 1080i HD as the Video Processor output.
Select 1080PsF HD as the Video Processor output.
Select 1080p HD as the Video Processor output.
Select 2K1080p HD as the Video Processor output.
3 Video Output Mode Selections Selection Descriptions
Normal (default)
Test Pattern
Normal video output from the processors.
The output of the test pattern generator.
