84
18 Dolby
Decoder Aux
Mode The Dolby Decoder outputs eight channels of decoded audio, plus an additional
Aux output which is a 2-channel (stereo) mixdown of one of the selected Dolby
Programs. This parameter determines how the Aux mixdown is produced. Lt/Rt
produces a stereo mixdown which takes rear surround channels into account (when
available).
Selecting Lo/Ro produces a stereo mixdown using only the front channels, Mono
produces a mono mixdown, and Mute produces full quality, high fidelity silence.
18 Dolby Decoder Aux
Mode
Selections Selection Descriptions
Lt/Rt
Lo/Ro
Mono
Mute
Produces an Aux stereo mixdown including the rear surround channels.
Produces an Aux stereo mixdown using only the front channels.
Produces an Aux mono mixdown.
Produces full quality high fidelity silence.
