136
Fiber1 3G Detect This parameter configures 3G operation of the Fiber 1 video input. The input can be
set for 1080p50/60 (single video), Dual Stream 3G SDI (two muxed videos), or Auto-
Detect whether the input is 1080p50/60 single or Dual Stream 3G video (requires
SMPTE Format ID to be present in the SDI Input). See parametr 4 SDI 1 3G Detect for
an illustration and details.
Fiber2 Input
Protect This parameter allows you to protect Input Fiber 2 from being taken by a Dual
Stream selection made in 6 Fiber1 3G Format Detect setting.
In the Normal setting (default), the Fiber 2 video signal always comes from the SDI 2
physical input. Choosing Dual Stream video in parameter 6 does not switch away
from the physical input.
In the Dual Stream setting, the FS2 assumes both channels of Dual Stream 3G video
are muxed onto a single wire at the Fiber 1 input. The Fiber 2 video signal is then
taken internally from the Fiber 1 Channel 2 signal instead of the Fiber 2 Input
connector.
Genlock Source Genlock Source selects the source of reference video used to genlock to, either
automatically or explicitly.
Note: HDMI can be used as a reference (with SYSTEM 8 Genlock Source set to Vid1
Input or Vid2 Input), but HDMI is not a valid reference source when the signal on
the HDMI input originates from a VESA-format computer DVI signal.
6 Fiber1 3G Format
Detect
Selections Selection Descriptions
Auto Detect (default)
1080p50/60
Dual Stream 3G
Automatically detects presence of 1080p50/60 or muxed video.
Configures the Fiber 1 input for 1080p50/60 video.
Configures Fiber 1 for Dual Stream 3G Video (uses SDI1 and SDI2 in
Input Crosspoint matrix).
7 Fiber2 Input Protect Selections Selection Descriptions
Normal (default)
Dual Stream
Fiber 2 cannot be used by Dual Stream 3G SDI video present on
Fiber 1.
Allows Fiber 2 to be used by a Dual Stream 3G SDI input present on
Fiber 1.
(8) Selections Selection Descriptions
Reference (default)
Vid1 Input
Vid2 Input
Free run
Use the signal on the Ref connector as the genlock source.
Use the Vid1 input signal as the genlock source.
Use the Vid1 input signal as the genlock source.
Free run mode (FS2 syncs to its own timebase, not locked to an external
source).
