Sleep/Wake Sources
The P351 [SleepWake RefSel] signal source for the sleep/wake function can be
any analog input, whether it is being used for another function or not, a
DeviceLogix software source (P90 [DLX Real OutSP1] thru P97 [DLX Real
OutSP8]), or a valid numeric edit configuration. Configuring the sleep/wake
source is done through P351 [SleepWake RefSel].
Also, [Anlg In
n Hi] and [Anlg Inn Lo] parameters have no effect on the function,
however, the factory calibrated result, [Anlg In
n Value] parameter, is used. In
addition, the absolute value of the calibrated result is used, thus making the
function useful for bipolar direction applications.
The analog in loss function, configured by the [Anlg In
n LssActn] parameter, is
unaffected and therefore operational with the sleep/wake function, but not tied
to the sleep or wake levels and is triggered off the [Anlg In
n Raw Value]
parameter.
Refer to the PowerFlex 750-Series Programming Manual, publication
, for more details.
