Rockwell Automation 20G PowerFlex 750-Series AC Drives User Manual
Page 421
Rockwell Automation Publication 750-RM002B-EN-P - September 2013
421
Appendix A
1313
Set
Motor Data Source
-
R
R
R
R
O-Enum
1 = Database (Y)
2 = Drive NV (Y)
3 = Motor NV (N)
1315
Set
Motor Type
-
R
R
R
R
O-Enum
1 = Rotary Permanent Magnet (Y)
2 = Rotary Induction (Y)
3 = Linear Permanent Magnet (N)
4 = Linear Induction (N)
1317
Set
Motor Polarity
-
Y
Y
Y
Y
1320
Set
Motor Rated Peak Current
-
N
N
N
N
N-IM
1321
Set
Motor Rated Output Power
-
Y
Y
Y
Y
Y-IM
1322
Set
Motor Overload Limit
-
Y
Y
Y
Y
1323
Set
Motor Integral Thermal Switch
-
N
N
N
N
1324
Set
Motor Max Winding Temperature
-
N
N
N
N
1325
Set
Motor Winding To Ambient Capacitance
-
N
N
N
N
1326
Set
Motor Winding To Ambient Resistance
-
N
N
N
N
2310
Set
PM Motor Flux Saturation
-
N
N
N
N
PM Motor only
1339
Set
PM Motor Rated Torque
-
N
N
N
N
Rotary PM Motor only
1340
Set
PM Motor Torque Constant
-
N
N
N
N
Rotary PM Motor only
1342
Set
PM Motor Rated Force
-
N
N
N
N
Rotary PM Motor only
1343
Set
PM Motor Force Constant
-
N
N
N
N
Rotary PM Motor only
1330
Set
Rotary Motor Inertia
-
N
Y
Y
N
Rotary Motor only
1332
Set
Rotary Motor Max Speed
-
N
N
N
N
Rotary Motor only
1333
Set
Rotary Motor Damping Coefficient
-
N
N
N
N
Rotary Motor only
2311
Set
Rotary Motor Fan Cooling Speed
-
N
N
N
N
Rotary Motor only
2312
Set
Rotary Motor Fan Cooling Derating
-
N
N
N
N
Rotary Motor only
1336
Set
Linear Motor Mass
-
N
N
N
N
Linear Motor only
1337
Set
Linear Motor Max Speed
-
N
N
N
N
Linear Motor only
1338
Set
Linear Motor Damping Coefficient
-
N
N
N
N
Linear Motor only
2313
Set
Linear Motor Integral Limit Switch
-
N
N
N
N
Linear Motor only
1349
Set
Induction Motor Magnetization Reactance
-
N
N
N
N
Ind Motor only
1350
Set
Induction Motor Rotor Resistance
-
N
N
N
N
Ind Motor only
1352
Set
Induction Motor Rated Slip Speed
-
Y
Y
Y
N
Ind Motor only
1370
Set
Load Type
N
N
N
N
N
DScale
1371
Set
Transmission Ratio Input
N
N
N
N
N
DScale
1372
Set
Transmission Ratio Output
N
N
N
N
N
DScale
1373
Set
Actuator Type
N
N
N
N
N
DScale
1374
Set
Actuator Lead
N
N
N
N
N
DScale
1375
Set
Actuator Lead Unit
N
N
N
N
N
DScale
1376
Set
Actuator Diameter
N
N
N
N
N
DScale
Table 30 - PowerFlex 755 Safety Drive Module Optional Attributes
ID
Access
Attribute
N
F
P
V
T
Conditional Implementation
