Rockwell Automation 20G PowerFlex 750-Series AC Drives User Manual
Page 425
Rockwell Automation Publication 750-RM002B-EN-P - September 2013
425
Appendix A
562
Set
Commutation Self-Sensing Current
-
-
N
N
N
PM Motor only
O-Value = #
563
Set
Commutation Polarity
-
-
N
N
N
PM Motor only
250
Set
Feedback Commutation Aligned
-
-
Y
Y
Y
O-Enum
2 = Motor Offset (N)
3 = Self-Sense (Y)
570
Set
Frequency Control Method
-
R
-
-
-
O-Enum
128 = Fan/Pump Volts/Hertz (Y)
129 = Sensorless Vector (Y)
130 = Sensorless Vector Economy (Y)
600
Get
Output Frequency
-
R
Y
Y
Y
610
Set
Stopping Action
-
R
R
R
R
O-Enum
2 = Ramped Decel Disable (FPV/Y)
3 = Current Decel Hold (PV/N)
4 = Ramped Decel Hold (PV/Y)
128 = DC Injection Brake (IM/Y)
129 = AC Injection Brake (IM/Y)
612
Set
Stopping Time Limit
-
-
N
N
N
613/354
Set
Resistive Brake Contact Delay
-
N
N
N
N
PM Motor only
614
Set
Mechanical Brake Control
-
N
N
N
N
615
Set
Mechanical Brake Release Delay
-
N
N
N
N
616
Set
Mechanical Brake Engage Delay
-
N
N
N
N
870
Set
DC Injection Brake Current
-
Y
Y
Y
Y
Ind Motor only
872
Set
DC Injection Brake Time
-
Y
Y
Y
Y
Ind Motor only
871
Set
Flux Braking Enable
-
Y
Y
Y
Y
Ind Motor only
627
Set
Power Loss Action
-
Y
Y
Y
Y
O-Enum
2 = Decel Regen (Y)
628
Set
Power Loss Threshold
-
Y
Y
Y
Y
629
Set
Shutdown Action
-
N
N
N
N
O-Enum
1 = Drop DC Bus (N)
630
Set
Power Loss Time
-
Y
Y
Y
Y
637
Get
Converter Capacity
-
N
N
N
N
638/262
Get
Bus Regulator Capacity
-
N
N
N
N
646
Set
Motor Overload Action
-
N
N
N
N
O-Enum
1 = Current Foldback (N)
647
Set
Inverter Overload Action
-
Y
Y
Y
Y
O-Enum
1 = Current Foldback (Y)
128 = Reduce PWM Rate (Y)
129 = PWM Foldback (Y)
659
Get
CIP Axis Alarms
Y
Y
Y
Y
Y
904
Get
CIP Axis Alarms - RA
Y
Y
Y
Y
Y
695
Set
Motor Overspeed User Limit
-
Y
Y
Y
Y
697
Set
Motor Thermal Overload User Limit
-
Y
Y
Y
Y
699
Set
Inverter Thermal Overload User Limit
-
N
N
N
N
Table 30 - PowerFlex 755 Safety Drive Module Optional Attributes
ID
Access
Attribute
N
F
P
V
T
Conditional Implementation
