Rockwell Automation Publication 750-RM002B-EN-P - September 2013 139
Feedback and I/O Chapter 2
Related PowerFlex 753 drives Level Select parameter information noted below.
Depending on the PowerFlex 750-Series Option Module(s) installed in the drive,
related Level Select parameter information noted below.
Parameter No. Parameter Name Description
230 RO0 Sel Selects the source that energizes the relay output.
231 RO0 Level Sel Selects the source of the level that is compared.
232 RO0 Level Sets the level compare value.
233 RO0 Level CmpSts Status of the level compare, and a possible source for a relay or transistor
output.
240 TO0 Sel Selects the source that energizes the relay or transistor output.
241 TO0 Level Sel Selects the source of the level that is compared.
242 TO0 Level Sets the level compare value.
243 TO0 Level CmpSts Status of the level compare, and a possible source for the transistor output.
Parameter No. Parameter Name Description
10 RO0 Sel Selects the source that energizes the relay output.
11 RO0 Level Sel Selects the source of the level that is compared.
12 RO0 Level Sets the level compare value.
13 RO0 Level CmpSts Status of the level compare, and a possible source for a relay or transistor
output.
20 RO1 Sel or TO0 Sel Selects the source that energizes the relay or transistor output.
21 RO1 Level Sel or
TO0 Level Sel Selects the source of the level that is compared.
22 RO1 Level or TO0
Level Sets the level compare value.
23 RO1 Level CmpSts
or TO0 Level
CmpSts Status of the level compare, and a possible source for a relay or transistor
output.
30 TO1 Sel Selects the source that energizes the transistor output.
31 TO1 Level Sel Selects the source of the level that is compared.
32 TO1 Level Sets the level compare value.
