132 Rockwell Automation Publication 750-RM002B-EN-P - September 2013
Chapter 2 Feedback and I/O
Drive Status Conditions
For PowerFlex 750-Series drives utilizing an option module, the table below
shows an overview of the selectable configurations for the drive’s digital output
Sel parameters.
Refer the PowerFlex 750-Series Programming Manual, publication 750-PM001 ,
for specific parameter bit level details.
Parameter No. Parameter Name Description
220
(1)
(1) PowerFlex 753 drives only.
Digital In Sts Status of the digital inputs resident on the main control board (Port 0).
227
(1)
Dig Out Setpoint Controls Relay or Transistor Outputs when chosen as the source. Can be
used to control outputs from a communication device using DataLinks.
233
(1)
RO0 Level CmpSts Status of the level compare, and a possible source for a relay or transistor
output.
720 PTP PsnRefStatus Displays the current operating status of the Point-To-Point Position
Planner in the Position Referencing.
724 Psn Reg Status Indicates status of position control logic.
730 Homing Status Indicates status of position control logic.
933 Start Inhibits Indicates which condition is preventing the drive from starting or running.
935 Drive Status 1 Present operating condition of the drive.
936 Drive Status 2 Present operating condition of the drive.
937 Condition Sts 1 Status of conditions that can result in the drive taking action (faulting),
based on configuration of protective functions.
945 At Limit Status Status of dynamic conditions within the drive that are either active or a
limit is being applied.
952 Fault Status A Indicates the occurrence of conditions that have been configured as faults.
These conditions are from P937 [Condition Sts 1].
953 Fault Status B Indicates the occurrence of conditions that have been configured as faults.
959 Alarm Status A Indicates the occurrence of conditions that have been configured as
alarms. These events are from P937 [Condition Sts 1].
960 Alarm Status B Indicates the occurrence of conditions that have been configured as
alarms.
961 Type 2 Alarms Indicates the occurrence of conditions that have been configured as
alarms.
1089 PID Status Status of the Process PI regulator.
1103 (2)
(2) PowerFlex 755 drives only.
Trq Prove Status Displays the status bits for TorqProve.
1210 (2) Profile Status Indicates status of speed profile/position indexer control logic.
1
(3)(4)
(3) Option modules can be used in Ports 4, 5, and 6 of PowerFlex 753 drives.
(4) Option modules can be used in Ports 4, 5, 6, 7, and 8 of PowerFlex 755 drives.
Dig In Sts Status of the digital inputs.
7
(3)(4)
Dig Out Setpoint Controls Relay or Transistor Outputs when chosen as the source. Can be
used to control outputs from a communication device using DataLinks.
13
(3)(4)
RO0 Level CmpSts Status of the level compare, and a possible source for a relay or transistor
output.
50 (5)
(5) Port 14: DeviceLogix software parameters.
DLX DigOut Sts Provides the individual on/off status of the DLX Logic Command word bits.
51 (5) DLX DigOut Sts2 Provides the individual on/off status of the 16 DLX DOPs.
