248 Rockwell Automation Publication 20P-UM001I-EN-P - February 2013
Appendix A Supplemental Drive Information
Table 86 - Schaffner and Schaffner Alternative Filters
A 4P1 460V AC EMI-FFP-480-9, Code 8270 (was RF 3009-SIEI) RF 3007-FTF, Code 7670 (Rasmi / EuroTek) RF 3010-MHU
6P0 EMI-FFP-480-9, Code 8270 (was RF 3009-SIEI) RF 3007-FTF, Code 7670 (Rasmi / EuroTek) RF 3010-MHU
010 EMI-FFP-480-24, Code 8271 (was RF 3024-SIEI) RF 3016-FTF, Code 7671 (Rasmi / EuroTek) RF 3010-MHU
014 EMI-FFP-480-24, Code 8271 (was RF 3024-SIEI) RF 3016-FTF, Code 7671 (Rasmi / EuroTek) RF 3016-MHU
019 EMI-FFP-480-24, Code 8271 (was RF 3024-SIEI) RF 3030-FTF, Code 8082 (Rasmi / EuroTek) RF 3025-MHU
027 EMI-FFP-480-30, Code 8272 (was RF 3030-SIEI) RF 3030-FTF, Code 8082 (Rasmi / EuroTek) RF 3040-MHU
035 EMI-FFP-480-40, Code 8273 (was RF 3040-SIEI) RF 3042-FTF, Code 7672 (Rasmi / EuroTek) RF 3040-MHU
045 RF 3045-FLP, Code 8073 (Rasmi / EuroTek) RF 3055-FTF, Code 7673 (Rasmi / EuroTek) RF 3050-MHU
052 RF 3055-FLP, Code 8078 (Rasmi / EuroTek) RF 3055-FTF, Code 7673 (Rasmi / EuroTek) RF 3070-MHU
073 RF 3100-FLP, Code 8075 (Rasmi / EuroTek) RF 3075-FTF, Code 7674 (Rasmi / EuroTek) RF 3100-MHU
086 RF 3100-FLP, Code 8075 (Rasmi / EuroTek) RF 3100-FTF, Code 7675 (Rasmi / EuroTek) RF 3100-MHU
100 RF 3100-FLP, Code 8075 (Rasmi / EuroTek) RF 3100-FTF, Code 7675 (Rasmi / EuroTek) RF 3100-MHU
129 RF 3150-FLP, Code 8076 (Rasmi / EuroTek) RF 3130-FTF, Code 7676 (Rasmi / EuroTek) RF 3130-MHU
B 167 RF 3180-FLP, Code 8077 (Rasmi / EuroTek) RF 3180-FTF, Code 7677 (Rasmi / EuroTek) RF 3180-MHU
207 RF 3250-MHU – –
250 RF 3250-MHU – –
330 RF 3400-MHU – –
412 RF 3600-MHU – –
C 495 RF 3600-MHU – –
667 RF 3800-MHU – –
D 830 RF 31k0-MHU – –
996 RF 31k6-MHU – –
1K1 RF 31k6-MHU – –
1K3 RF 31k6-MHU – –
1K4 RF 31k6-MHU – –
Frame Drive Current
Rating Code Voltage
Class Rasmi Filters Rasmi Alternative Type Filters
Part Number Part Number Part Number
Frame Drive Current
Rating Code
Voltage
Class Schaffner Filters Schaffner Alternative Type Filters
Part Number Part Number Part Number
A 7P0 230V FN 258-7-29 FN 3258-7-44 FN 3270H-10-44
9P0 FN 258-16-29 FN 3258-16-44 FN 3270H-10-44
012 FN 258-16-29 FN 3258-16-44 FN 3270H-20-44
020 FN 258-30-33 FN 3258-30-33 FN 3270H-20-44
029 FN 258-30-33 FN 3258-30-33 FN 3270H-35-33
038 FN 258-42-33 FN 3258-42-33 FN 3270H-50-34
055 FN 258-55-34 FN 3258-55-34 FN 3270H-65-34
073 FN 258-75-34 FN 3258-75-34 FN 3270H-80-35
093 FN 258-100-35 FN 3258-100-35 FN 3270H-100-35
110 FN 258-130-35 FN 3258-130-35 FN 3270H-150-99
B 146 FN 258-180-40 FN 3258-180-40 FN 3270H-150-99
180 FN 258-180-40 FN 3258-180-40 FN 3270H-200-99
218 FN 258-250-40 FN 3359-250-28 FN 3270H-250-99
265 FN 258-250-40 FN 3359-320-99 FN 3270H-320-99
360 – FN 3359-400-99 FN 3270H-400-99
434 – FN 3359-400-99 FN 3270H-600-99
C 521 – FN 3359-600-99 FN 3270H-600-99
700 – FN 3359-800-99 FN 3270H-800-99
D 875 FN 3359-1000-99 – FN 3270H-1000-99
1K0 FN 3359-1000-99 – FN 3270H-1000-99
