212 Rockwell Automation Publication 20P-UM001I-EN-P - February 2013
Appendix A Supplemental Drive Information
Specifications
Category Specification
Agency
Certification According to file E59272 for the series of the approved devices.
In conformity with the following European Directives:
EMC Directive (2004/108/EC)
Low Voltage Directive (2006/95/EC)
Standards applied:
EN 50178: 1997
EN 61800-3: 2004
Australian Communications and Media Authority
In conformity with the following:
Radio communications Act: 1992
Radio communications Standard: 2008
Radio communications Labelling Notice: 2008
Standards applied:
EN 61800-3:2004
The drive is also designed to meet the following specifications:
NFPA 70 - US National Electrical Code
Category Specification
Drive Type Full Wave Regen, 6 Pulse, Regulated Field Supply
Protection Heat Sink Thermistor: Monitored by microprocessor overtemp trip
Drive Armature Overcurrent Trip
Software Overcurrent Trip:
Hardware Overcurrent Trip: Programmable, 0…250% of rated current (175% default)
Based on armature circuit fusing
Line Transients: Up to 2000 volts peak per IEC 6100-4-5
Control Logic Noise Immunity: Showering arc transients up to 1500V peak
Power Ride-Thru: 15 milliseconds at full load
Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Environment (1)
(1) PowerFlex DC drives must be installed in a Pollution Degree 2 environment. See Pollution Degree Ratings According to EN 61800-5-1 on
page 42 for details.
Altitude: 1000 m (3300 ft) max. without derating.
De-rate output power by 1.2% for every 100 meters (328ft) above
1000 meters (3300ft).
Maximum Surrounding Air
Temperature IP20, NEMA/UL Type
Open: 0…50° C (32…122° F), typical.
De-rate 1.25% for every 1° C over 50° C (122° F), to 55° C (131° F).
Additional cooling is required for temps. above 55° C.
Storage Temp. (all const.): –25…55° C (–13…131° F)
Atmosphere: Important: Drive must not be installed in an area where the
ambient atmosphere contains volatile or corrosive gas, vapors or
dust. If the drive is not going to be installed for a period of time, it
must be stored in an area where it will not be exposed to a
corrosive atmosphere.
Relative Humidity: Operating: 5…85% non-condensing
Storage: 5…95% non-condensing
Shock: 15G peak for 11ms duration (
±
1.0 ms)
Vibration: 0.152 mm (0.006 in.) displacement, 1G peak
