Frame A and B Recommended AC Input Line Fuses
AC input line fuses are externally mounted for frame A and B drives and must be
sourced separately. See Fuse Code FS1 in
.
Table 46 - 230V AC Input Drives
Table 47 - 460V AC Input Drives
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC Line
Amps
Bussmann
Ferraz Shawmut (Gould Shawmut)
Ferrule FWP
Type
Ferrule Fuse
Block
North American
FWP Type
North
American
Fuse Block
Ferrule A70QS
Type
North American A70P
/ A70QS Type
A 7P0
7
5.7
FWP-10A14F
CH143D
FWP-10B
–
A70QS10-14F
A70P10-4
9P0
9
7.4
FWP-15A14F
FWP-15B
–
A70QS16-14F
A70P15-4
012
12
9.8
FWP-20A14F
FWP-20B
–
A70QS20-14F
A70P20-4
020
20
16
FWP-25A14F
FWP-25B
–
A70QS25-14F
A70P25-4
029
29
24
FWP-40A22F
CH223D
FWP-40B
–
A70QS40-22F
A70QS40-4
038
38
31
FWP-63A22F
FWP-60B
–
A70QS63-22F
A70QS60-4
055
55
45
FWP-80A22F
FWP-80B
–
A70QS80-22F
A70QS80-4
073
73
60
–
–
FWP-100A
–
–
A70QS100-4K
093
93
76
–
–
FWP-150A
BH-1133
–
A70QS150-4K
110
110
90
–
–
FWP-175A
–
A70QS175-4K
B 146
146
119
–
–
FWP-250A
–
A70QS250-4
180
180
147
–
–
FWP-300A
–
A70QS300-4
218
218
178
–
–
FWP-350A
–
A70QS350-4
265
265
217
–
–
FWP-400A
BH-3144
–
A70QS400-4
360
360
294
–
–
FWP-600A
–
A70QS600-4K
434
434
355
–
–
FWP-600A
–
A70QS600-4
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC Line
Amps
Bussmann
Ferraz Shawmut (Gould Shawmut)
Ferrule FWP
Type
Ferrule Fuse
Block
North American
FWP Type
North
American
Fuse Block
Ferrule A70QS
Type
North American A70P
/ A70QS Type
A 4P1
4.1
3.3
FWP-10A14F
CH143D
FWP-10B
–
A70QS10-14F
A70P10-4
6P0
6
4.9
FWP-10A14F
FWP-10B
–
A70QS10-14F
A70P10-4
010
10
8.2
FWP-20A14F
FWP-20B
–
A70QS20-14F
A70P25-4
014
14
11.4
FWP-25A14F
FWP-25B
–
A70QS25-14F
A70P25-4
019
19
15.5
FWP-25A14F
FWP-25B
–
A70QS25-14F
A70P25-4
027
27
22.1
FWP-40A22F
CH223D
FWP-40B
–
A70QS40-22F
A70QS40-4
035
35
28.6
FWP-63A22F
FWP-60B
–
A70QS63-22F
A70QS60-4
045
45
36.8
FWP-80A22F
FWP-80B
–
A70QS80-22F
A70QS80-4
052
52
42.5
FWP-80A22F
FWP-80B
–
A70QS80-22F
A70QS80-4
073
73
59.6
–
–
FWP-100A
–
–
A70QS100-4K
086
86
70.3
–
–
FWP-150A
BH-1133
–
A70QS150-4K
100
100
81.7
–
–
FWP-175A
–
A70QS175-4K
129
129
105.4
–
–
FWP-175A
–
A70QS175-4K
B 167
167
136.4
–
–
FWP-300A
–
A70QS300-4
207
207
169.1
–
–
FWP-350A
–
A70QS350-4
250
250
204.3
–
–
FWP-400A
BH-3144
–
A70QS400-4
330
330
269.6
–
–
FWP-600A
–
A70QS600-4K
412
412
336.6
–
–
FWP-600A
–
A70QS600-4
