Rockwell Automation 20P PowerFlex Digital DC Drive User Manual
Page 182
182
Rockwell Automation Publication 20P-UM001I-EN-P - February 2013
Chapter 3
Programming and Parameters
INPUT / OUT
P
UT
Anal
og O
u
tp
ut
s
66
67
68
69
[Anlg Out1 Sel]
[Anlg Out2 Sel]
[Anlg Out3 Sel]*
[Anlg Out4 Sel]*
Selects the source of the value that drives the analog output.
*This parameter is used to configure an analog output on the
I/O Expansion circuit board. See
- Optional Analog and Digital I/O
Expansion Circuit Board.
Options:
Default:
Default:
Default:
Default:
12 =
13 =
18 =
14 =
“Motor Speed”
“Motor Curr”
“Fld Current”
“Motor Volts”
16-bit
Int
Fil
e
Gr
oup
No
.
Parameter Name & Description
See
page 110
for symbol descriptions
Values
Da
ta
T
yp
e
Rela
ted
No.
Option (Par)
Scaling of Analog Output Value
No.
Option (Par)
Scaling of Analog Output Value
0 = “Off” (Not used)
n/a
18 = “Fld Current” (Par 234)
0-10V = 0-100% of Par 280 [Nom Mtr Fld
Amps]
1 =
“Spd Ref Out” (Par 385)
±10V = ±100% of Par 45 [Max Ref Speed] 19 = “UserDefined0” (Par 503)
±10V = ±2047 in Par 503 [UserDefined0]
2 =
“Trim Ramp” (Par 42)
±10V = ±100% of Par 45 [Max Ref Speed] 20 = “UserDefined1” (Par 504)
±10V = ±2047 in Par 504 [UserDefined1]
3 =
“Ramp In” (Par 110)
±10V = ±100% of Par 45 [Max Ref Speed] 21 = “UserDefined4” (Par 507)
±10V = ±2047 in Par 507 [UserDefined4]
4 =
“Ramp Out” (Par 113)
±10V = ±100% of Par 45 [Max Ref Speed] 22 = “UserDefined5” (Par 508)
±10V = ±2047 in Par 508 [UserDefined5]
5 =
“Spd Draw Out” (Par 1018)
±10V = ±100% of Par 45 [Max Ref Speed] 23 = “UserDefined6” (Par 509)
±10V = ±2047 in Par 509 [UserDefined6]
6 =
“Trim Speed” (Par 43)
±10V = ±100% of Par 45 [Max Ref Speed] 24 = “Field Ref” (Par 500)
(1)
(1)
Not used for permanent magnet motor applications.
0-10V = 0-100% of Par 280 [Nom Mtr Fld
Amps]
7 =
“Spd Reg In” (Par 118)
±10V = ±100% of Par 45 [Max Ref Speed] 25 = “PID Output” (Par 774)
±10V = ±10000 in Par 774 [PID Output]
8 =
“Spd Reg Out” (Par 236)
±10V = ± 100% of Par 179 [Nom Mtr Arm
Amps]
26 = “Out Volt Lvl” (Par 921)
±10V = ±100% Par 175 [Rated Motor Volt]
9 =
“Torque Ref” (Par 14)
±10V = ± 100% of Par 179 [Nom Mtr Arm
Amps]
27 = “Fld Cur Max” (Par 467)
0-10V = 0-100% of Par 280 [Nom Mtr Fld
Amps]
10 = “Trim Torque” (Par 40)
±10V = ± 100% of Par 179 [Nom Mtr Arm
Amps]
28 = “Filtered Spd” (Par 924)
±10V = ±100% of Par 45 [Max Ref Speed]
11 = “Torq Reg In” (Par 41)
±10V = ± 100% of Par 179 [Nom Mtr Arm
Amps]
29 = “Filtered Cur” (Par 928)
±10V = ± 200% of Par 179 [Nom Mtr Arm
Amps]
12 = “Motor Speed” (Par 121)
±10V = ±100% of Par 45 [Max Ref Speed] 30 = “Output Power” (Par 1052)
±10V = ± 200% of Par 179 [Nom Mtr Arm
Amps] x Par 175 [Rated Motor Volt]
13 = “Motor Curr” (Par 199)
±10V = ± 200% of Par 179 [Nom Mtr Arm
Amps]
31 = “Roll Diam” (Par 1154)
0-10V = 0-100% of Par 1153 [Max
Diameter]
14 = “Motor Volts” (Par 233)
±10V = ±100% of Par 175 [Rated Motor
Volt]
32 = “Tension Ref” (Par 1180)
0-10V = 0-100% of Par 1153 [Max
Diameter]
15 = “Analog In 1” (Par 70)
±10V = ±10V on Analog Input 1
33 = “Torque Curr” (Par 1193)
±10V = ± 200% of Par 179 [Nom Mtr Arm
Amps]
16 = “Analog In 2” (Par 75)
±10V = ±10V on Analog Input 2
34 = “Winder Ref” (Par 1217)
±10V = ±100% of Par 45 [Max Ref Speed]
17 = “Analog In 3” (Par 80)
±10V = ±10V on Analog Input 3
35 = “Active Comp” (Par 1213)
±10V = ± 200% of Par 179 [Nom Mtr Arm
Amps]
