Supplemental Drive Information
Appendix A
Alternate Dynamic Brake
Resistor Kits and DC Output
Contactors
The following alternate dynamic brake resistor kits and/or DC output contactors
may be used with the corresponding PowerFlex DC drives but must be sourced
separately from the drive.
Table 81 - 230V AC Input Drives
Table 82 - 460V AC Input Drives
Fr
am
e
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Hp
Dynamic Brake Resistor
Kit Cat. No.
Armature
Voltage
(Volts)
DB Resistor
Size (ohms)
DB
Resistor
Size
(Watts)
Brake
Amps
Required
DC Loop Contactor Cat. No.
(2)
DC Contactor
Crimp Lugs Cat.
No.
(3)
Drive w/No Dynamic Brake
Drive w Dynamic Brake
B
360
360
294
100
1370-DBL76
240
1.4
290
171.43
ABB_EHDB360C2P-1L2S
ABB_EHDB360C-1L22SS
(4)
434
434
355
125
CUTLER-HAMMER_G3AP50
(Qty 4 - two in series, two in
parallel)
240
0.5
1458
651
ABB_EHDB520C2P-1L2S
ABB_EHDB520C-1L22SS
C
521
521
426
150
HUBBELL_Y139W322GB
240
0.322
6221
781
700
700
572
200
(1)
240
–
–
–
ABB_EHDB800C2P-1L2S
ABB_EHDB800C-1L22SS
D
875
875
715
250
240
–
–
–
ABB_EHDB960C2P-1L2S
ABB_EHDB960C-1L22SS
1K0
1050
858
300
240
–
–
–
SIEMENS-MFG_14-193-101-58-
2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty
1)
(1) No Dynamic Brake Resistor kit available for this drive rating - must be sourced locally.
(2)
Coil voltage = 115V AC, 50/60Hz.
(3)
See DC Contactor Crimp Lug Kit Specifications on page
for more information.
(4) Wire and Lug size dependant on enclosure dimensions and local codes.
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC Line
Amps
Hp
Dynamic Brake Resistor Kit
Cat. No.
Armature
Voltage
(Volts)
DB Resistor
Size (ohms)
DB
Resistor
Size
(Watts)
Brake Amps
Required
DC Loop Contactor Cat. No.
(2)
DC Contactor
Crimp Lugs
Cat. No.
(3)
Drive w/No Dynamic Brake
Drive w Dynamic Brake
B 330
330
269.6
200
1370-DBH79
500
0.7
280
714.29
ABB_EHDB360C2P-1L2S
ABB_EHDB360C-1L22SS
(4)
412
412
336.6
250
HUBBELL_Y95W808GB
500
0.808
7292
–
ABB_EHDB520C2P-1L2S
ABB_EHDB520C-1L22SS
C 495
495
404.4
300
HUBBELL_Y101W595GB
500
0.595
6069
–
ABB_EHDB520C2P-1L2S
ABB_EHDB520C-1L22SS
667
667
544.9
400
HUBBELL_Y109W542GB
500
0.542
6439
–
ABB_EHDB800C2P-1L2S
ABB_EHDB800C-1L22SS
D 800
830
678.1
500
(1)
500
0.463
6338
–
ABB_EHDB960C2P-1L2S
ABB_EHDB960C-1L22SS
960
996
813.7
600
500
0.322
6221
–
SIEMENS-MFG_14-193-101-58-2 (Qty
2)
SIEMENS-MFG_14-193-101-58-2
(Qty 1)
1K1
1162
949.4
700
500
0.322
6221
–
SIEMENS-MFG_14-193-101-58-2 (Qty
2)
SIEMENS-MFG_14-193-101-58-2
(Qty 1)
1K3
1328
1085.0
800
500
0.255
5718
–
CUTLER-HAMMER_6702ED636-2 (Qty
2)
CUTLER-HAMMER_6702ED636-2 (Qty
1)
1K4
1494
1220.6
900
500
0.255
5718
–
CUTLER-HAMMER_6702ED636-2 (Qty
2)
CUTLER-HAMMER_6702ED636-2 (Qty
1)
(1) No Dynamic Brake Resistor kit available for this drive rating - must be sourced locally.
(2) Coil voltage = 115V AC, 50/60Hz.
(3) See DC Contactor Crimp Lug Kit Specifications on page
for more information.
(4) Wire and Lug size dependant on enclosure dimensions and local codes.
