Rockwell Automation Publication 20P-UM001I-EN-P - February 2013 153
Programming and Parameters Chapter 3
APPL
IC
AT
IONS
PID Co
ntr
ol
763 [PID Feedback]
Analog input feedback value received from the transducer position (dancer) or
tension (load cell).
Default:
Min/Max:
0
–/+10000
16-bit
Int
772 [PID Output Sign]
Determines whether the output of the PID regulator is bipolar or positive (clamp of
the negative side).
Default:
Options:
1 =
0 =
1 =
“Bipolar”
“Positive”
“Bipolar”
16-bit
Int
773 [PID Output Scale]
Scale factor for Par 774 [PID Output]. The value of this parameter depends on to
which parameter you want to send the PID regulator output.
Default:
Min/Max:
1.00
–/+100.00
Real 774
774 [PID Output]
Displays the PID regulator output.
Note: This parameter can be assigned to an analog output in order to provide a
cascaded reference in multi-drive systems.
Default:
Min/Max:
Read Only
–/+10000
16-bit
Int
782 [PID Target]
Parameter number to which the PID Output value will be written.
Note: Added option 48 “Reserved” for firmware version 5.002.
Default: 0 = “Not Used” 16-bit
Int
Options:
Fil
e
Gr
oup
No
. Parameter Name & Description
See page 110 for symbol descriptions
Values Da
ta
T
yp
e
Rela
ted
A
A
A
A
A
0 = “Not Used” 17 = “Max Fld Pct” (Par 467) 34 = “UsrDefined15” (Par 518)
1 = “Cur Lim Pos” (Par 8) 18 = “Reserved” 35 = “Load Comp” (Par 698)
2 = “Cur Lim Neg” (Par 9) 19 = “UsrDefined0” (Par 503) 36 = “Out Volt Lvl” (Par 921)
3 = “Reserved” 20 = “UsrDefined1” (Par 504) 37 = “Reserved”
4 = “Reserved” 21 = “UsrDefined2” (Par 505) 38 = “Speed Ratio” (Par 1017)
5 = “TrqRedCurLim” (Par 13) 22 = “UsrDefined3” (Par 506) 39 = “Reserved”
6 = “Torque Ref” (Par 39) 23 = “UsrDefined4” (Par 507) 40 = “Reserved”
7 = “Trim Torque” (Par 40) 24 = “UsrDefined5” (Par 508) 41 = “Tension Red” (Par 1179)
8 = “Reserved” 25 = “UsrDefined6” (Par 509) 42 = “Reserved”
9 = “Trim Ramp” (Par 42) 26 = “UsrDefined7” (Par 510) 43 = “Reserved”
10 = “Trim Speed” (Par 43) 27 = “UsrDefined8” (Par 511) 44 = “CloseLp Comp” (Par 1208)
11 = “Reserved” 28 = “UsrDefined9” (Par 512) 45 = “Reserved”
12 = “Reserved” 29 = “UsrDefined10” (Par 513) 46 = “Reserved”
13 = “Reserved” 30 = “UsrDefined11” (Par 514) 47 = “Reserved”
14 = “Adaptive Ref” (Par 183) 31 = “UsrDefined12” (Par 515) 48 = “Reserved”
15 = “Reserved” 32 = “UsrDefined13” (Par 516)
16 = “Reserved” 33 = “UsrDefined14” (Par 517)
