Figure 63 – Rockwell Automation 20P PowerFlex Digital DC Drive User Manual
Page 224
224
Rockwell Automation Publication 20P-UM001I-EN-P - February 2013
Appendix A
Supplemental Drive Information
Table 54 - 575V AC Input Drives
Figure 63 - Frame A Field Circuit Fuses Location
Figure 64 - Frame B Field Circuit Fuses Location
Fram
e Drive
Current
Rating Code
Field
Amps
Quantity Type
Bussmann
Ferraz Shawmut
(Gould Shawmut)
SIBA
B
067
20
2
10 x 38 mm
FWC-25A10F
A60Q25-2
60 033 05.25
101
135
270
405
Bottom View of Drive without Fan
Field circuit fuses
Bottom View of Drive with Fan
Top View of Drive
Field circuit fuses
