Appendix A
Supplemental Drive Information
Table 83 - 575V AC Input Drives
Table 84 - 690V AC Input Drives
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Hp
Dynamic
Brake
Resistor Kit
Cat. No.
Armature
Voltage
(Volts)
DB Resistor
Size (ohms)
DB
Resistor
Size
(Watts)
Brake
Amps
Required
DC Loop Contactor Cat. No.
(2)
DC Contactor
Crimp Lugs
Cat. No.
(3)
Drive w/No Dynamic Brake
Drive w Dynamic Brake
B
067
67.5
55.1
50
(1)
600
5.93
–
–
ABB_EHDB220C2P-1L2S
ABB_EHDB220C-1L22SS
(4)
101
101
83
75
600
3.95
–
–
ABB_EHDB220C2P-1L2S
ABB_EHDB220C-1L22SS
135
135
110
100
600
2.96
–
–
ABB_EHDB220C2P-1L2S
ABB_EHDB220C-1L22SS
270
270
221
200
600
1.48
–
–
ABB_EHDB360C2P-1L2S
ABB_EHDB360C-1L22SS
405
405
331
300
600
0.988
–
–
ABB_EHDB520C2P-1L2S
ABB_EHDB520C-1L22SS
C
540
540
441
400
600
0.741
–
–
ABB_EHDB650C2P-1L2S
ABB_EHDB650C-1L22SS
675
675
551
500
600
0.593
–
–
ABB_EHDB800C2P-1L2S
ABB_EHDB800C-1L22SS
D
810
810
662
600
600
0.494
–
–
ABB_EHDB960C2P-1L2S
ABB_EHDB960C-1L22SS
1K0
1080
882
800
600
0.370
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
1K2
1215
993
900
600
0.329
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
1K3
1350
1103
1000
600
0.296
–
–
CUTLER-HAMMER_6702ED636-2 (Qty 2)
CUTLER-HAMMER_6702ED636-2 (Qty 1)
1K6
1688
1379
1250
600
0.237
–
–
CUTLER-HAMMER_6702ED636-2 (Qty 2)
CUTLER-HAMMER_6702ED636-2 (Qty 1)
(1) No Dynamic Brake Resistor kit available for this drive rating - must be sourced locally.
(2) Coil voltage = 115V AC, 50/60Hz.
(3) See DC Contactor Crimp Lug Kit Specifications on page
for more information.
(4) Wire and Lug size dependant on enclosure dimensions and local codes.
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Hp
Dynamic
Brake
Resistor Kit
Cat. No.
Armature
Voltage
(Volts)
DB Resistor
Size (ohms)
DB
Resistor
Size
(Watts)
Brake
Amps
Required
DC Loop Contactor Cat. No.
(2)
DC Contactor
Crimp Lugs
Cat. No.
(3)
Drive w/No Dynamic Brake
Drive w Dynamic Brake
C
452
452
369
400
(1)
700
1.03
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
(4)
565
565
462
500
700
0.826
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
D
678
678
554
600
700
0.688
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
791
791
646
700
700
0.590
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
904
904
739
800
700
0.516
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
1K0
1017
831
900
700
0.459
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
1K1
1130
923
1000
700
0.413
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
1K2
1243
1016
1100
700
0.375
–
–
SIEMENS-MFG_14-193-101-58-2 (Qty 2)
SIEMENS-MFG_14-193-101-58-2 (Qty 1)
1K4
1413
1154
1250
700
0.330
–
–
CUTLER-HAMMER_6702ED636-2 (Qty 2)
CUTLER-HAMMER_6702ED636-2 (Qty 1)
1K5
1582
1292
1400
700
0.295
–
–
CUTLER-HAMMER_6702ED636-2 (Qty 2)
CUTLER-HAMMER_6702ED636-2 (Qty 1)
(1) No Dynamic Brake Resistor kit available for this drive rating - must be sourced locally.
(2) Coil voltage = 115V AC, 50/60Hz.
(3) See DC Contactor Crimp Lug Kit Specifications on page
for more information.
(4) Wire and Lug size dependant on enclosure dimensions and local codes.
