240 Rockwell Automation Publication 20P-UM001I-EN-P - February 2013
Appendix A Supplemental Drive Information
Table 78 - 690V AC Input Drives
Frame Drive Current
Rating Code DC Amps AC Line Amps Hp IP00 (Open Style)
Line Reactor Cat No. Line Reactor kW (HP) AC Input Contactor Cat. No.
C 452 452 369 400 1321-3RB500-C – 100-D420ED11
565 565 462 500 1321-3RB600-C – 100-D630ED11
D 678 678 554 600 1321-3R750-C – 100-D630ED11
791 791 646 700 1321-3R750-C – 100-D860ED11
904 904 739 800 1321-3R1000-C – 100-D860ED11
1K0 1017 831 900 1321-3R1000-C – 100-D860ED11
1K1 1130 923 1000 2 X 1321-3R600-C – 100-G700KD22
1K2 1243 1016 1100 2 X 1321-3R600-C – 100-G860KD22
1K4 1412.5 1154 1250 2 X 1321-3R750-C – 100-G1200KD12
1K5 1582 1292 1400 2 X 1321-3R750-C – 100-G1200KD12
