Rockwell Automation 20P PowerFlex Digital DC Drive User Manual
Page 181
Rockwell Automation Publication 20P-UM001I-EN-P - February 2013
181
Programming and Parameters
Chapter 3
INPUT
/ O
U
TPU
T
An
al
og In
pu
ts
1045
[Anlg In1 Cmp Eq]
Provides an indication, after the amount of time specified in Par 1044 [Anlg
In1 Cmp Dly] has elapsed, when the value set in parameter 1043 [Anlg In1
Cmp Err] has been reached.
• “0” = The value of analog input 1 is above or below the value set in Par
1043 [Anlg In1 Cmp Err].
• “1” = The value of analog input 1 is within the range set in Par 1043
[Anlg In1 Cmp Err].
Notes: This parameter can be assigned to a digital output. See Analog Input
Signal Comparison on page
for more information.
Default:
Min/Max:
Read Only
0 / 1
16-bit
Int
1042,
1043,
1044
1404
[Analog In1 Value]
Value of the signal at analog input 1. Units based on the value set in Par 71
[Anlg In1 Config].
Default:
Min/Max:
Units:
Read Only
-/+20.00
V or mA
Real
71
1405
[Analog In2 Value]
Value of the signal at analog input 2. Units based on the value set in Par 76
[Anlg In2 Config].
Default:
Min/Max:
Units:
Read Only
-/+20.00
V or mA
Real
76
1406
[Analog In3 Value]
Value of the signal at analog input 3. Units based on the value set in Par 81
[Anlg In3 Config].
Default:
Min/Max:
Units:
Read Only
-/+20.00
V or mA
Real
81
An
alog O
utpu
ts 62
63
64
65
[Anlg Out1 Scale]
[Anlg Out2 Scale]
[Anlg Out3 Scale]
[Anlg Out4 Scale]
Scaling of the analog outputs.
Default:
Min/Max:
1.00
–/ +10.00
Real
Fil
e
Gr
oup
No
.
Parameter Name & Description
See
page 110
for symbol descriptions
Values
Da
ta
T
yp
e
Rela
ted
