Preface
Standard Drive Catalog
Number Explanation, Cont.
Standalone Regulator
Catalog Numbers All catalog numbers below are provided with conformally coated circuit boards.
Position
1-3 4 5 6 7 8-10 11 12 13 14 15 16
20P 4 1 A D 4P1 R A 0 N N N
a b c d e f g h i j k l
g
Field Supply
Code Type
R Single-Phase Regulated
h
Packaging/Documentation
Code Shipping Carton User Manual
A Yes Yes
i
HIM
Code Operator Interface
0 Blank Cover
Standard - for user installed options, see
Human Interface and Wireless Interface
Modules on page 9.
j
I/O Options
Code Control
N
None (8 - 24V DC Digital Inputs,
4 Digital Outputs, 3 Analog Inputs,
and 2 Analog Outputs are Standard)
k
Communication Options
Code Description
N None
l
Cabinet Options
Code Type
N None
Standard - for user installed options, see
Communication Option Kits on page 10.
All I/O Options are purchased separately and
are user installed. See I/O Options on page 9.
230V / 460V AC Input Regulators 575V / 690V AC Input Regulators Field Amps
Catalog Number Catalog Number
23PMD4 23PMF4 40
23PMD7 23PMF7 70
23PAMP
(1)
(1) Gate Amplifier - used with all voltage classes of the Standalone Regulator. Note: The Standalone Regulator and Gate Amplifier are
currently sold through Rockwell Automation Drive Systems only. Consult the factory for availability.
