Thermal motor monitoring
Temperature monitoring of the motor with PTC and earth−fault detection
10
l
360 EDS82EV903 EN 3.0
Activation
)
Note!
ƒ In the Lenze setting, the temperature monitoring of the motor is switched
off!
ƒ If you are dealing with several parameter sets, you must activate the
monitoring in each parameter set!
1. Connect the monitoring circuit of the motor to X2/T1 and X2/T2.
– If 1.6 k
W < R < 4 kW the monitoring is activated.
2. Set the reaction of the controller:
– C0119 = 0 or 3: Temperature monitoring of the motor is switched off
– C0119 = 1 or 4: TRIP fault message (keypad display: OH3
a)
– C0119 = 2 or 5: Warning signal (keypad display: OH51
e)
Verification
Connect the PTC input to a fixed resistor:
ƒ R > 4 k
W: A fault message OH3 or OH51 must be initiated.
ƒ R < 1 k W: A fault message must not be initiated.
