GeoSteer

System

Installation Overview

Operator’s

Manual

3

There are a number of options available for each sub-category. Each of these options comes with their own installation and
operational manuals that should be referred to during their part of the installation.

1

Display Kits

GeoSteer is compatible with multiple Display options. The Displays are ordered as a separate component and include their own
installation and operator’s instructions. The Display Operator’s Manual will show how the Display and Display Harnesses are
installed on a vehicle and how they are connected to the GeoSteer Harnesses. There are three connections between the Display
and the GeoSteer Main Cable Harness that need to be connected:
ETHERNET TO DISPLAY – This connection is a RJ-45 connector that is plugged into the Ethernet port on the Display

or Display Harness to provide communications between the Display and the GeoSteer Control Unit.

POWER ACTIVATION – This connection is connected to the Display or Display Harness that provides a signal that

commands the GeoSteer to power up. When this signal is turned off, the GeoSteer will power down.

UNSWITCHED POWER – This is connected to a power source that provides 12 volts of unswitched DC power to the

GeoSteer. The power source should not be connected to a power supply that is connected to the vehicle’s ignition. This
source should be shown or explained in the Display Operator’s Manual.

The Display Kit will provide the necessary harnesses and instructions to provide power to the GeoSteer system and to allow
communications between the two. Use those instructions to complete the Display installation and to connect the Display to the
GeoSteer system after the Display mount has been installed.

2

GeoSteer System Kits

The GeoSteer System Kits represent the parts that are common on all installations. The GeoSteer System kits are ordered as
two parts, the System Kits and the GeoDock (GPS and Cell Modem Antenna assembly).

The System Kits include a version of the GeoSteer Control Unit, the GeoSteer Main Harness, User’s Manual, a version of the
GeoDock, GPS coax cable, and when required, the Cell Modem coax cable. There are four base versions of this kit that are
sold in different parts of the world. The listed regions are for reference only and can change over time. They System Kits are:

Note: Refer to your AutoSteer dealer for exact part numbers.

GeoSteer CDMA – North America

GeoSteer No Cell – Australia and South America

GeoSteer GSM Europe – Europe

GeoSteer GSM Australia – Australia

There are two GeoDock versions that can be ordered. The one that is ordered depends on if the GeoSteer System Kit requires a
Cell Modem or not. The two GeoDock Kits are:
GeoDock Pro – This GeoDock assembly has a built in Cell Modem antenna installed.

GeoDock Pro – No Cell – This GeoDock assembly is the same as the GeoDock Pro except the cell antenna and coax cable

are not provided.
