NTRIP
Operator’s Manual 111
General (Original Screen)
Figure 4-24 NTRIP General
The General option displays the status of the NTRIP connection. The General screen provides the following information:
• Current Status – The lets the user know if the system is connected to the NTRIP stream or not.
• Server – This is the Server that the system is configured to connect to.
• Stream – This is the Stream that the system is configured to connect to.
Note: If no profile exists, both the Connect and Disconnect buttons will be grayed out and no Server or Stream data from a
previous connection will be shown.
Note: Prior to connecting to a NTRIP stream, the stream must be created first in the Profile list.
Profile
Figure 4-25 NTRIP Profile
The Profile screen provides a way to create, delete, select, and connect to an active NTRIP profile. A profile must be created
prior to connecting to a NTRIP stream. The Profile screen provides the following information:
• Select Profile – This is a list of the available profiles (no profiles are shown in Figure 4-28).
