Chapter 2 Avaya P330-ML Layer 2 CLI Commands
84 Avaya P330-ML Reference Guide
/ {no-flowcontrol|asym-tx-only|sym-only|sym-and-
asym-rx}
Example:
set port channel
User level: privileged, supervisor.
Use the set port channel command to enable or disable a Link Aggregation
Group (LAG) interface on the switch. LAG creation requires a LAG name to be
specified. There is no default name.
You can also add or remove a port from an existing LAG. When adding or removing
a port to an existing LAG, type the same LAG-name. All ports in the LAG are
configured with the parameters of the first port that is added to the LAG. These
parameters include port administrative status, speed, duplex, autonegociation
mode, VLAN ID, tagging mode, binding mode, and priority level.
The ports added to a LAG must belong to the same LAG group - refer to the “LAG”
marking on device’s front panel.
L When adding a port to an existing LAG, type the same LAG name, otherwise
you will create a new LAG.
module Number of the module.
port Number of the port on the module. If you do not specify a
number, all the ports on the module are set. Alternatively,
you can specify a range of ports separated by a dash, for
example, 4/5-13 for ports 5 to 13 on module 4.
no-flowcontrol The port will advertise no pause capabilities.
asym-tx-only The port will advertise asymmetric Tx pause capabilities only.
sym-only The port will advertise symmetric pause capabilities only.
sym-and-asym-rx The port will advertise both symmetric and asymmetric Rx
pause capabilities.
P330-N# set port auto-negotiation-flowcontrol-
advertisement 1/5 asym-tx-only
Port 1/5 pause capabilities was set
