Chapter 2 Avaya P330-ML Layer 2 CLI Commands
Avaya P330-ML Reference Guide 191
Output fields:
Field Description
Spanning tree Status of whether Spanning-Tree Protocol is enabled or
disabled
Designated
Root MAC address of the designated spanning-tree root bridge
Designated
Root Priority Priority of the designated root bridge
Designated
Root Cost Total path cost to reach the root
Designated
Root Port Port through which the root bridge can be reached (shown only
on nonroot bridges)
Root Max Age Amount of time a BPDU packet should be considered valid
Hello Time Number of times the root bridge sends BPDUs
Root Forward
Delay This time value, measured in units of hundredths of a second,
controls how fast a port changes its spanning state when
moving towards the Forwarding state.
Bridge ID
MAC ADDR Bridge MAC address used in the sent BPDUs
Bridge ID
Priority Bridge priority
Bridge Max
Age The value that all bridges use for MaxAge when this bridge is
acting as the root.
Bridge Hello
Time The value that all bridges use for HelloTime when this bridge is
acting as the root.
Bridge
Forward Delay The value that all bridges use for ForwardDelay when this
bridge is acting as the root.
Tx Hold Count The value used by the Port Transmit state machine to limit the
maximum transmission rate.
Soanning Tree
Version The version of Spanning Tree Protocol the bridge is currently
running
