PSB-2000 Series User Manual
84
Fig. Status Pins
26
EXT CONT (J3)
1
2
25
CV
CC
ALARM
CH1 status
26
EXT CONT (J3)
1
2
25
CV
CC
ALARM
CH2 status
Inside of
PSB-2000
Series
Fig. Photocoupler
current
Internal current
2mA
I=1mA or less
R
V
※ Select and use proper voltage or resistance so that
the open collector current does not exceed 1mA.
