PSB-2000 Series User Manual
104
Address Setting
Description The interface has two addresses: Personal
Computer Address, and System Address. The type
of address that is used depends on whether the unit
is the master connected to a PC or a slave unit
connected over the local bus. If the System Address
is set to 1, then that unit is designated as the master
unit. A Personal Computer Address can then be
assigned to the master unit as well. Each slave unit
should be assigned a System Address when
connected to a master unit.
NOTE The System Address of the unit directly connected
to the PC must be 1.
The system is not guaranteed to operate if several
slave units connected to the master unit have the
same System Address.
Do not assign the same address to several slave
units.
Address Range Remark
System
Address 1 to 30 Address 1 is used for the master unit.
Other addresses are for the slave units. The
slave units connected to the master unit must
have different System Addresses.
Personal
Computer
Address
(GPIB
address) 1 to 30 The Personal Computer Address may be set only
when the System Address is set to 1. For the
optional GPIB interface, it is the GPIB address.
For the RS232 and USB interfaces, no Personal
Computer Address is used.
