GETTING STARTED
25
27 J1 control
signal input
connector
This connector is used for parallel and serial
control for master/slave operation. The optional
frame link cables must be used with this
connector.
28 J2 control
signal output
connector
This connector is used for parallel and serial
control for master/slave operation. The optional
framelink cables must be used with this
connector.
29 Exhaust Grill Air taken into the unit from the front is blown out
through this grill. Leave a gap of a least 30cm or
more behind the rear panel for good ventilation.
If there is an object obstructing the rear panel, the
temperature inside the power supply unit may
rise excessively.
30
Functional
ground
terminal
The unit can be grounded using this terminal
31 AC INPUT Connect the AC power cable supplied with the
unit with this plug receptacle and supply AC
power to the unit.
