EXTERNAL CONTROL

103

Connection Cables

Procedure

Use the proprietary modular cables for the local
bus connection (GRJ-1101).

Use standard GPIB cables for the GPIB
connections.

Use USB cables (applicable for Full Speed USB
or greater) for the USB connections.

Use interlink cables for the RS-232C connection.
The pin assignment is as shown below. Note that
normal crossover cables may not be used.

Fig. RS-232C
Cable Connection

Personal computer

PSB-002

D-Sub 9

pin socket

2

RxD

<->

3

D-Sub 9 pin

socket

3

TxD

<->

2

4

DTR

<->

6

5

GND

<->

5

6

DSR

<->

4

7

RTS

<->

8

8

CTS

<->

7

FG

<->

FG
