When connecting units together using the local bus
connection, any of the local bus ports on the
interface board can be used as the input or output.
Use the shortest modular cables possible to connect
each unit. Terminate the start and end of the daisy-
chain-connected units by shorting CN2 jumper
pins on the interface boards with the shorting
connectors
1 . Disconnect the shorting connectors
from all the other interface boards
2
. Using the
example figure above, ―Local Bus Connection‖, the
CN2 jumpers on System Addresses 2 and 3 should
be removed.
1
The interface board is short-circuited with the
jumper pin before shipment.
2
Keep the disconnected connectors. Do not discard
them.
