GETTING STARTED

13

Single Unit
Control of
Parallel/Series
Operation

The PSB-L series uses a single power supply unit
(acting as the master unit) to control all connected
slave units for series or parallel operation. In parallel,
up to 4 units can be controlled (including the master)
to increase the total power. In series, a maximum of 2
units (including the master) can be used.

External Control
Function

The external control function allows external voltage
and restistance-based control, voltage and current
monitoring, output on/off control, alarm output and
CV/CC status output.

Interface Boards There are two optional interface boards for remote

control.

PSB-001: GPIB and local bus board.

PSB-002: RS-232C, USB and local bus board.

Note also that one of these options must be used to
program sequences for the PSB-L series. See page 85
for further details.

Dual Channel
Model
(PSB-2400L2)

Equipped with two 400W output channels for a
wide variety of applications.

Delay (DLY)
Function:
(PSB-2400L2
Only)

The delay function introduces a switching delay
between channel 1 and 2. The delay function can set
a rising delay (the time to turn on) and a falling delay
(the time to turn off).

Tracking
Function:
(PSB-2400L2
Only)

The channel 2 setting is made equal to that of
channel 1 when the tracking function is activated.
Thereafter, both channels change synchronously.
