PSB-2800L
Item
Single Parallel Series
800L 800L x 2 800L x 3 800L x 4 800L + 800L
800W 1600W 2400W 3200W 1600W
Voltage Setting
SLOW 10mV
FAST 1V
Range 0V-82V
Min. display
digit 10mV
Current Setting
SLOW 10mA 100mA 90mA 80mA 10mA
FAST 1A 10A 9A 8A 1A
Range 0A-82A 0A-164A 0A-246A 0A-328A 0A-82A
Min. display
digit 10mA 100mA 10mA
Power Setting
SLOW 10W 100W 10W
FAST 100W 1000W 100W
Range 10W-820W 20W-1640W 30W-2460W 40W-3280W 10W-820W
Min. display
digit 1W
OVP Setting
SLOW 100mV
FAST 10V
Range 1V-84V
Min. display
digit 10mV
OCP Setting
SLOW 100mA 200mA 300mA 400mA 100mA
FAST 10A 20A 30A 40A 10A
Range 1A-84A 2A-168A 3A-252A 4A-336A 1A-84A
Min. display
digit 10mA 100mA 10mA
For parallel connections, the smallest value that can be displayed (Min. display digit) for
current is 100mA. When some model combinations are used in parallel, the actual current
setting resolution may be different to the display resolution. In this situation the display
may not update with only one click of the encoder.
