PSB-2000 Series User Manual
100
Connector type RJ-11 (6-pin modular)
Pin 2 (D+), pin 3 (D-)
Applicable cable Modular cable: GRJ-1101 (500mm 6P6C RJ11)
Q’ty of connectable units A maximum of 10 units can be connected in a
daisy chain configuration.
Terminator The terminator is built-in. It may be turned on or
off with a jumper pin.
Q’ty of ports 2 ports, non-directional
PSB-002 Specifications (standard)
RS-232C
Specifications
Conforms to the RS-232C Standards.
Data transmission speed 57600[bps]
Data bit Data: 8 [bits], stop bit: 1 [bit], parity: none
Max. cable length 10[m]
Connector type D-sub, 9-pin, plug
Applicable cable
Mass-marketed interlink cable (Socket 9-pin to
socket 9-pin)
Q’ty of connectable units One-to-one connection only
USB
Specifications
Conforms to the USB Standards, Revision .2.0.
Full speed: 12 [Mbps]
Connector type USB series B
Device class USB CDC/ACM Class.
Vendor code 2184
Product code 0031
Power supply Self-powered only
Q’ty of connectable units
Maximum of 127 units are connectable through
USB hubs.
Local bus
Specifications
Conforms to the RS-485 Standards. Proprietary
protocol.
Max. cable length 10 [m]
Connector type
RJ-11 (6-pin modular)
Pin 2 (D+), pin 3 (D-)
Applicable cable Modular cable: GRJ-1101 (500mm 6P6C RJ11)
Q’ty of connectable units
Maximum of 10 units are connectable through
daisy chain connection.
