PSB-2000 Series User Manual

130

Command Completion (*OPC)

This command sets bit 0 of the standard event status register (ESR)
when all current overlapped commands have been processed.

Setting

*OPC
Sets bit 0 of the ESR when all current overlapped
commands are complete. A SRQ is generated depending
on the status of the ESE register and SRE register.

Query

*OPC?
The value “1” is returned when all current commands are
completed.

Wait for Completion (*WAI)

This command waits for command completion.

Setting

*WAI
Prevents new commands/queries from being executed
until all outstanding overlapped commands have
completed.

Query

None

Local Address Setting (:ADDR)

This command specifies the address of a slave unit on the local bus.

Setting

:ADDR
The range is from 1 to 30.
Specifies the address of a slave on the local bus to be
controlled. This command causes no error even if an out-
of-range System Address is specified.

Application
example

:ADDR3
Sets the System Address of the power supply (slave) to 3.
:ADDR1
Sets the System Address of the power supply to 1. A
System Address of 1 means that the unit is also set as a
master unit.

Query

None

Remark

The default setting is 1 (master unit). Reset to 1
after completion of communication with the local bus.
