PSB-2000 Series User Manual
158
PSB-2400L (Part 2/2)
Item
Parallel Series
2400L+ 2800L x
2
2400L + 2400L
+ 2800L x 2
2400L + 2800L x
3
2400L + 2400L
2000W 2400W 2800W 800W
Voltage Setting
SLOW 10mV
FAST 1V
Range 0V to 82V
Min. display digit 10mV
Current Setting
SLOW 100mA 60mA 70mA 10mA
FAST 10A 6A 7A 1A
Range 0A-205A 0A-246A 0A-287A 0A-41A
Min. display digit 100mA 10mA
Power Setting
SLOW 100W 10W
FAST 1000W 100W
Range 50W-2050W 60W-2460W 70W-2870W 10W-410W
Min. display digit 1W
OVP Setting
SLOW 100mV
FAST 10V
Range 1V-84V
Min. display digit 10mV
OCP Setting
SLOW 500mA 600mA 700mA 100mA
FAST 50A 60A 70A 10A
Range 5A-210A 6A-252A 7A-294A 1A-42A
Min. display digit 100mA 10mA
For parallel connections, the smallest value that can be displayed (Min. display digit) for
current is 100mA. When some model combinations are used in parallel, the actual current
setting resolution may be different to the display resolution. In this situation the display
may not update with only one click of the encoder.
