OPERATION

43

How to Set the Current

Procedure

1. Make sure that the A key is lit green. If not,

press the A key to turn it on.

V

A

W

2. Set the current with the encoder wheel.

How to Set Power

Procedure

1. Make sure that both the V and A keys are lit. If

not, press the V and A keys to turn them on.
(Both keys need to be lit when setting the
power.)

V

A

W

If the A key is pressed while keeping the V key
depressed, the Current LED display can be
used to enter the power setting. (The ―A‖
indicator will turn turn off and the ―W‖
indicator will turn on, indicating that the
setting has changed from current to power.)
See the figure below, “Voltage and Power”.

If the V key is pressed while keeping the A key
depressed, the Voltage LED display can be
used to enter the power setting. (The ―V‖
indicator will turn turn off and the ―W‖
indicator will turn on, indicating that the
setting has changed from voltage to power.)
See the figure below, “Current and Power”.

2. Set the power with the encoder wheel.
