Protective functions

Over-voltage protection (OVP):
Fixed

15

Stops oscillation when the output voltage exceeds 110% of
rated voltage. (Output Off)

Over-voltage protection (OVP):
Variable

16

Presettable range: 1V to 84V on front panel.(PSB-L series)
Presettable range: 1V to 840V on front panel.(PSB-H
series)
Stops oscillation when OVP works. (Output Off)

Over-current protection (OCP):
Fixed

15

Stops oscillation when output current exceeds 110% of
rated current. (Output Off)

Over-current protection (OCP):
Variable

16

Presettable range: 1A to 42A on front panel.(PSB-L series)
Presettable range: 0.1A to 3.15A on front panel.(2400H)
Presettable range: 0.1A to 6.3A on front panel.(2800H)
Stops oscillation when OCP works. (Output Off) (2800L:
84A)

Overheat protection (OHP)

15

When the internal heat sink temperature is over the
thermal switch value, the unit will turn off.

15

Press the POWER switch again to reset.

16

Press the POWER switch again or press the ESC key to reset.

Others

Cooling method

Forced cooling with fan motor

To-GND voltage

±DC500V(PSB-L series)
±DC100V(PSB-H series)

Dielectric strength voltage

Power In terminals - frame: AC1500V, 1min.
Power In terminals - output terminals: AC2300V, 1min.

Insulation resistance

Power In terminals - frame: DC500V(PSB-L),
DC1000V(PSB-H), 30MΩ or more.
Power In terminals - output terminals: DC500V(PSB-L),
DC1000V(PSB-H), 30MΩ or more. (PSB-L)
Output terminals - frame: DC500V(PSB-L), DC1000V(PSB-
L), 30MΩ or more

Outside dimensions
(Projections not included.)

210mm(W)×124mm(H)×290mm(D)

Weight

PSB-2400L, PSB-2400H: Approx. 5kg
PSB-2800L, PSB-2400L2, PSB-2800LS: Approx. 7kg
PSB-2800H: Approx. 6kg

Environmental Conditions

Operating temperature range 0ºC to +40ºC
Operating humidity range

30% RH to 80% RH (No dew condensation)

Storage temperature range

-20ºC to +70ºC

Storage humidity range

30% RH to 80% RH (No dew condensation)
