APPENDIX
149
Specifications
Output
Model PSB-2400L PSB-2800L PSB-2400L2 PSB-2800LS
Rated output voltage 80.00V 80.00V 80.00V×2CH 80.00V
Setting accuracy 0.1% setting ±2 digit (23ºC ±5ºC)
Resolution 10mV
Display accuracy 0.2% reading ±2 digit (23ºC ±5ºC)
Rated output current 1 40.00A 80.00A 40.00A×2CH 80.00A
Setting accuracy 0.2% setting ±2 digit (23ºC ±5ºC)
Resolution 10mA
Display accuracy 0.3% reading ±2 digit (23ºC ±5ºC)
Rated output power 2 400W 800W 400W×2CH 800W
Setting accuracy ±10W
Resolution 10W
Display accuracy 0.5% reading ±5 digit (23ºC ±5ºC)
1 The maximum output current through the front output terminals is 40A.
2 Switching from the constant-voltage (CV) or constant-current (CC) mode into the
constant-power (CP) mode or vice versa is subject to over-shoot ringing, etc.
Model PSB-2400H PSB-2800H
Rated output voltage 800.0V
Setting accuracy 0.1% setting ±2 digit (23ºC ±5ºC)
Resolution 100mV
Display accuracy 0.2% reading ±2 digit (23ºC ±5ºC)
Rated output current 1 3.00A 6.00A
Setting accuracy 0.2% setting ±2 digit (23ºC ±5ºC)
Resolution 10mA
Display accuracy 0.3% reading ±2 digit (23ºC ±5ºC)
Rated output power 2 400W 800W
Setting accuracy
±10W
Output voltage should be at least 1% of the rated voltage
Resolution 10W
Display accuracy 0.5% reading ±5digit (23ºC ±5ºC)
1 The maximum output current through the front output terminals is 3A(2400H) or
6A(2800H).
2 Switching from the constant-voltage (CV) or constant-current (CC) mode into the
constant-power (CP) mode or vice versa is subject to over-shoot ringing, etc.
