OPERATION

79

Fig.External
Voltage/
Resistance
Control
Terminal(CV)

1

2

25

26

EXT CONT (J3)

Negative output

terminal of CH1

0V

10V

0Ω

10kΩ

CH1

External

control

※ Use a shielded cable or twisted

pair wires for this control.

1

2

25

26

EXT CONT (J3)

Negative output

terminal of CH2

0V

10V

0Ω

10kΩ

CH2

External

control

※ Use a shielded cable or twisted

pair wires for this control.

Output voltage

FS

10V

External

voltage

Output voltage

FS

10kΩ

External

resistance
