13 CH2 COM COM pin for channel 2. Connected with
the negative output terminal of channel
2.
14 CH1 EXT CV
CONTROL IN Constant-voltage control input pin for
the channel 1.
In the external voltage control mode, an
external voltage of 0V to 10V can be
used to control the output voltage from
~0V to the rated output voltage.
In the external resistance control mode,
an external resistance of 0kΩ to 10kΩ
can be used to control the output
voltage from ~0V to the rated output
voltage.
15 CH1 EXT CC
CONTROL IN Constant-current control input pin for
channel 1.
In the external voltage control mode, an
external voltage of 0V to 10V can be
used to control the ouput current from
~0A to the rated output current.
In the external resistance control mode,
an external reistance of 0kΩ to 10kΩ can
be used to control the output current
from ~0A to the rated output current.
16 CH1 COM COM pin for channel 1.
Connected with the negative output
terminal of channel 1.
17 CH1 EXT V MON
OUT Output voltage monitor pin for channel
1.
Outputs approx. 0V to 10V to represent
0V to the rated output voltage.
