Serial Data Debug Solutions
50 919586 RevA
Encoding Table Reference
For convenience, the following standard tables provide data for 5b/6b, 3b/4b, and Control Symbols.
5 B /6 B
Input RD = -1 RD = +1 Input RD = -1 RD = +1
EDCBA abcdei EDCBA abcdei
D.00 00000 100111 011000 D.16 10000 011011 100100
D.01 00001 011101 100010 D.17 10001 100011
D.02 00010 101101 010010 D.18 10010 010011
D.03 00011 110001 D.19 10011 110010
D.04 00100 110101 001010 D.20 10100 001011
D.05 00101 101001 D.21 10101 101010
D.06 00110 011001 D.22 10110 111010
D.07 00111 111000 000111 D.23 † 10111 111010 000101
D.08 01000 111001 000110 D.24 11000 110011 001100
D.09 01001 100101 D.25 11001 100110
D.10 01010 010101 D.26 11010 010110
D.11 01011 110100 D.27 † 11011 110110 001001
D.12 01100 001101 D.28 11100 001110
D.13 01101 101100 D.29 † 11101 101110 010001
D.14 01110 011100 D.30 † 11110 011110 100001
D.15 01111 010111 101000 D.31 11111 101011 010100
K.28 11100 001111 110000
Table 3-2.† Same code used for K.x.7
3 B /4 B
Input RD = -1 RD = +1 Input RD = -1 RD = +1
HGF fghj HGF fghj
D.x.0 000 1011 0100 K.x.0 000 1011 0100
D.x.1 001 1001 K.x.1 ‡ 001 0110 1001
D.x.2 010 0101 K.x.2 ‡ 001 1010 0101
D.x.3 011 1100 0011 K.x.3 011 1100 0011
D.x.4 100 1101 0010 K.x.4 100 1101 0010
D.x.5 101 1010 K.x.5 ‡ 001 0101 1010
D.x.6 110 0110 K.x.6 ‡ 001 1001 0110
D.x.P7 † 111 1110 0001
D.x.A7 † 111 0111 1000 K.x.7 † ‡ 111 0111 1000
