Operator's Manual
919586 RevA 185
Decode annotations unique to USB2 include the following (some annotations are not shown in the screen-shot):
USB2 Decode Annotations

Label - Identifier showing data type and parameter association. Typically shown as octal numbers.

SDI - Source/Destination Identifier

Data - Bits 29 - 11.

SSM - Sign/Status Matrix

Pa - Parity

Msg - Displays the symbolic information.

Symbols

Bits/Resolution

Pad

Status
Note: Specifications are subject to change without notice.
USB2 Decode Table Column Details
USB2 table column values available include the following:
