Marking the Enable checkbox enables the controls on the dialog.
Notice how MIPI D-PHY provides its own, unique table, statistics and set of test parameters for the
measurements.
Tip: Touch the protocol name on the top left of the Statistic or Table column headings to show corresponding
Physical and Decode Setup dialogs, respectively.
Show Decode
Note: If you do not have the MIPI D-PHY Serial Decode Option (D PHY-D), you won't see the Show Decode
checkbox beneath the Enable checkbox. Marking this checkbox (when you have the option) shows annotations
on your waveforms.
