Use the following sections to work through areas of the main dialog.
Enable, Show Decode, Setup Acquisition
Enable
Marking the Enable checkbox enables the controls on the dialog.
Notice how MIPI D-PHY provides its own, unique table and set of test parameters.
Tip: Touch the protocol name on the top left of the Statistic or Table column headings to show corresponding
Physical and Decode Setup dialogs, respectively.
