76

Starting up the Modbus

register
address in
mfc

number of
register

name / Description

r/w

type

0035…0036 2

device Type
Bürkert type number of the device

R

UINT16
ASCII_2

0037

1

ModusMFC
MFC Mode / Activation of the Autotune function.

The controller must be in normal mode. (ModusMFC = 0)

Autotune can be activated by writing a value of 2

R/W

UINT16

0038

1

Reset Totalizer

A value of 1 will reset the Totalizer value of the actual gas.
Clearing the value is needless.

W

UINT16

0039

1

Reset device

A value of 1 restarts the device. Clearing the value is
needless.

W

UINT16

1)

ASCII_2

An UINT16 value is interpreted as two characters. The high byte shows the first character.

e.g. 0x4142 → „AB“

e.g. Operating Medium “Luft” as 4 x UINT16

0x4C75
0x6674
0x0000
0x0000

e.g. device Type“8713” as 2 x UINT16

0x3837
0x3133

versions of the hardware

Returns 2 bytes, which are constructed as follows:
X.Y Range:
X

0 or ‚A‘ – ‚Z‘

Y

‚A‘ – ‚Z‘

e.g. 0x004B → K

0x414B → A.K

versions of the software

Returns 4 bytes, which are constructed as follows
X.YY Range:

X

‚A‘ – ‚Z‘

YY

0 – 99

e.g. 0x4101 → A.01

english

MFC Family
