Serial Communication
command number
command name 0x92
extSetpoint
request
Command
0x92
Byte count 5
data 1 byte
0
Internal set-point value settings
1 External set-point value settings
4 bytes
0 – 3
Set-point value [%] (float) 1)
response
Command
0x92
Byte count 7
Status 2 bytes, device status
data 1 byte
0
Internal set-point value settings
1 External set-point value settings
4 bytes
0 – 3
Set-point value [%] (float) 1)
Description
Available as of firmware version A.00.28.09.
determines the set-point value settings and describes the external set-point value as a percentage:
Internal = analog - the set-point value settings is assigned by the analog set-point value signal that is
created
External = digital via serial interface
do not use this command if you are using a bus device (PROFIBUS, deviceNet, etc.). The digital set-point
value settings via the serial interface has a higher priority.
1) First byte transferred: MSB
Example:
All data as hexadecimal numbers (prefix 0x) short frame
Primary master
Short address 0
data sent
data received
• Set-point value settings digital 0.0% ( 0x00000000 IEEE 754)
0xFF 0xFF 0x02 0x80 0x92 0x05 0x01 0x00 0x00 0x00 0x00 0x14
0xFF 0xFF 0x06 0x80 0x92 0x07 0x00 0x00 0x01 0x00 0x00 0x00 0x00 0x12
• Set-point value settings digital 50.0% ( 0x42480000 IEEE 754)
0xFF 0xFF 0x02 0x80 0x92 0x05 0x01 0x42 0x48 0x00 0x00 0x1E
0xFF 0xFF 0x06 0x80 0x92 0x07 0x00 0x00 0x01 0x42 0x48 0x00 0x00 0x18
