CANopen Start-up

6.4.4.

Overview of the mapped objects

process data

explanation

identification

Actual value

Actual value
(1 word = 2 bytes)
Value range 0 – 1000

RX (receive)

dec: 12288, 1
Hex: 3000, 1

INTEGER16

Set-point

Set-point value
(1 word = 2 bytes)
Value range 0 – 1000

Tx, Rx

dec: 12288, 2
Hex: 3000, 2

UNSIGNEd16

Active gas

Calibration of this gas is used for control,
gas 1 or gas 2
(1 word = 2 bytes) value range 0 – 1

RX (receive)

dec: 12288, 3
Hex: 3000, 3

UNSIGNEd16

Nominal flow Gas 1

Nominal flow in Nl/min of
calibration for gas 1
float = 4 bytes

RX (receive)

dec: 12288, 4
Hex: 3000, 4

REAL32

Nominal flow Gas 2

Nominal flow in Nl/min of
calibration for gas 2
float = 4 bytes

RX (receive)

dec: 12288, 5
Hex: 3000, 5

REAL32

Status limits

Bit field for states of device-internal threshold
value:
(1 word = 2 bytes)
see “9.1. description of bit fields”

RX (receive)

dec: 12288, 6
Hex: 3000, 6

UNSIGNEd16

Status errors

Bit field for device errors that are present.
(1 word = 2 bytes)
see “9.1. description of bit fields”

RX (receive)

dec: 12288, 7
Hex: 3000, 7

UNSIGNEd16

Status others

Bit field for current states in the controller.
(1 word = 2 bytes)
see “9.1. description of bit fields”

RX (receive)

dec: 12288, 8
Hex: 3000, 8

UNSIGNEd16
