52

Acyclic Data Transfer with
PROFIBUS, DeviceNet and CANopen

7.3.

Devicenet S-identity Object

S-identity Object

name

Description of the input data attributes

attribute address
(class, instanceat-
tribute; data type)
Dvn

Vendor Id

Read only
vendor's Id number.
Bürkerts deviceNet vendor Id 57h

dec: 1, 1, 1
Hex: 1, 1, 1

UINT

device Type

Read only
Numeric device identifier
Identification of the general product type.
This is type 0 (generic device).

dec: 1, 1, 2
Hex: 1, 1, 2

UINT

Product Code

Read only
The product code is 2, corresponding to the eds file.

dec: 1, 1, 3
Hex: 1, 1, 3

UINT

Revision

Read only
Revision of the element representing the identity
object. This is a structure of two bytes.

dec: 1, 1, 4
Hex: 1, 1, 4

WORd

Status

Read only
Combined status of the device.

dec: 1, 1, 5
Hex: 1, 1, 5

WORd

Serial Number

Read only
Serial number that is unique for all Bürkert devices.

dec: 1, 1, 6
Hex: 1, 1, 6

UdINT

Product Name

Read only
MFC/MFM

dec: 1, 1, 7
Hex: 1, 1, 7

SHORT_STRING

english

MFC Family
