56

Acyclic Data Transfer with
PROFIBUS, DeviceNet and CANopen

7.6.

S-Single Stage Controller Object

S-Single Stage controller Object

name

Description of the input data
attributes

attribute address
(class, instance
attribute; data
type)

Slot, index

index, Subindex

Dvn

Dpv1

canopen

data Type

Read Write
describes the data type of the
set-point value

Hex
0xC3 INT0
0xCA REAL

dec: 51, 1, 3
Hex: 33, 1, 3

USINT

dec: 1, 103
Hex: 1, 67

dec: 8960, 1
Hex: 2300, 1

UNSIGNEd8

data Units

Read Write
min. value 2048,
max. value 4103

list of units see
“9.2. Table of units”

"% "

"Units per thousand"

and the calibrated device unit

dec: 51, 1, 6
Hex: 33, 1, 6

UINT

dec: 1, 104
Hex: 1, 68

dec: 8960, 2
Hex: 2300, 2

UNSIGNEd16

Set-point

Read Write
The value format depends on the
data type.
The value unit is defined by the
value of the unit.

dec: 51, 1, 6
Hex: 33, 1, 6

INT

Or

REAL

dec: 1, 106
Hex: 1, 6A

dec: 8960, 3
Hex: 2300, 3

INTEGER16

Or

dec: 8960, 4
Hex: 2300, 4

REAL32

Status

Read only
This is not supported yet.
The return value is always 0.

dec: 51, 1, 6
Hex: 33, 1, 6

BYTE

dec: 1, 107
Hex: 1, 6B

dec: 8960, 5
Hex: 2300, 5

UNSIGNEd8

english

MFC Family
