Starting up the Modbus

exceptional reply

If a master device sends a request to a slave device, the master device expects a normal reply When the master
has transferred a request, one of the four events may occur:

• If the slave device receives the request without a data transfer error and the request can be processed normally,

a normal reply is sent back.

• If the slave device does not receive the request due to a data transfer error, no reply is sent back. The master

device program determines a timeout for the request.

• If the slave device determines a data transfer error, no reply is sent back. The master device program deter-

mines a timeout for the request.

• If the slave device receives the request without a data transfer error, but the request cannot be processed (e.g.

to read out a non-existent register), an exceptional reply is sent back which informs the master device about the
type of error. The exceptional reply has two fields that distinguishes it from a normal reply.

function code field

If the answer is normal, the slave sends back a copy of the function code included in the original request in the
appropriate field of the reply. If the reply is an exception, the value of the function code is exactly 0x80 hexa-
decimal numbers higher than it would be in a normal reply.

Data field
If the reply is an exception, the slave sends an exception code in the data field, that defines the operating status
of the slave which caused the exception.

example of an exceptional reply

Request (Read Input Register 0x68) register is outside the validity range

field name

value

Slave address

0x01

Function

0x04

Initial address high

0x00

Initial address low

0x68 (invalid register)

Number of high registers

0x00

Number of low registers

0x01

Error check

CRC

(high byte)

Error check

CRC

(low byte)
